Red Jacket CoreDEF Series - Temperature Data; Operating Data; Table 1. Electrical Service Information

Introduction Temperature Data
10
Temperature Data
*DEF will degrade with prolonged storage above 77°F (25°C). Refer to the DEF manufacturer’s guidelines for
proper storage.
Operating Data
Adjustable Pres-
sure Relief Kit
410881-001
Adjustable Pressure Relief Valve
w/1” NPT inlet/outlet
Check Valve* 410875-001
* NOTE: Check valve recommended with use of Adjustable Pressure Relief valve which is not designed to
hold system pressure.
Operating Temperature (Fluid) +12°F to +104°F (-11°C to +40°C)*
Table 1. Electrical Service Information
Model HP KW
Voltage
(+6% /-10% Hz PH
Max.
Current
(A)
Locked
Rotor
Amps
Capacitor
(F)
UMP Resistance (Including
Cable) ()
Min.
Transformer
Rating (KVA)
Black-
Grey
Black-
Brown
Grey-
Brown
DP75U1 3/4 0.56 230 60 1 4.5 13 17.5; 440V
5.9-
7.3
13.2-
16.2
18.9-
23.2 1.8
DP75U3 3/4 0.56 230 50 1 4.6 10 17.5; 440V
8.3-
10.2
17.5-
21.5
25.7-
31.5 1.8
DP200U1 2 1.5 230 60 1 10 35 40.0; 440V
2.1-
2.7
4.3-
5.3
6.2-
7.7 3.6
DP200U17 2 1.5 400 50 3 4.9 21 –
8.7-
10.7
8.7-
10.7
8.7-
10.7 3.6
DP200U4 2 1.5 230 60 3 9.2 40 –
2.4-
3.0
2.4-
3.0
2.4-
3 .0 3.6
Item Part Number Description
