4” Standard Pump Installation, Operation & Service Manual Specifications
10
When using a Red Jacket IQ
TM
Control Unit with an UMP containing a Faradyne motor, IQ software 805-001C
(Version3.2) or newer, is required for proper operation of the system. The UMPs will have an ‘FM’ designation
printed on the UMP shell. Software upgrade kit part number is 410600-001.
Table 5 lists pump weights and lengths.
NOTE: The weights and lengths listed below are approximate values and will vary due to
manufacturing tolerances.
The optional trapper intake screen is available as a field installed accessory. Trapper options will change the length
of the UMP by 3.3 inches (83 mm). For installation instructions, see Red Jacket installation instructions #051-256-
1. For models with Floating Suction Adapter, add 2-3/8 inches (59 mm) and 4 pounds (1.8 kg).
Table 4.- Electrical Service Information (Use for UMPs Containing a Faradyne Motor with End View B)
Required power supply rating for 60 Hz, 1 phase motors is 208 - 230 Vac. For 50 Hz, 1 phase motors, required rating is 220 - 240 Vac.
3 phase motors required rating is 380 - 415 Vac.
UMP Model No. HP Hz PH
Voltag e
Fluctuation
Range
Max.
Load
Amps
Locked
Rotor
Amps
Winding Resistance (Ohms)
Capacitor Kit
(µF)Min. Max.
Black-
Orange
Red-
Orange Black-Red
AGUMP33R1,
UMP33R1
1/3 60 1 200 250 4 10 8.9 - 10.8 11.5 - 13.9 20.2 - 24.5 144-224-5 (17.5)
AGUMP75S1,
UMP75S1
3/4 60 1 200 250 6.5 19 4.7 - 5.7 7.1 - 8.6 11.7 - 14.1 144-224-5 (17.5)
AGUMP150S1,
UMP150S1
1-1/2 60 1 200 250 10.5 33 2.8 - 3.4 6.8 - 8.2 9.4 - 11.3 144-225-5 (25)
X3AGUMP150S1,
X3UMP150S1
1/1/2 60 1 200 250 10.5 33 2.8 - 3.4 6.8 - 8.2 9.4 - 11.3 144-225-5 (25)
AGUMP75S3-3,
UMP75S3-3
3/4 50 1 200 250 5.8 18 5.2 - 6.3 10.3 - 12.5 15.4 - 18.6 144-224-5 (17.5)
AGUMP150S3-3,
UMP150S3-3
1-1/2 50 1 200 250 10 31 2.8 - 3.4 13.4 - 16.3 16.1 - 19.5 144-225-5 (25)
X4AGUMP150S3,
X4UMP150S3
1-1/2 50 1 200 250 10 31 2.8 - 3.4 13.4 - 16.3 16.1 - 19.5 144-225-5 (25)
