RED DSMC SIDE HANDLE User Manual

DSMC2 REDVOLT XL MODULE CONNECTIONS
Figure: DSMC2 REDVOLTXLModule
# CONNECTOR CONNECTORTYPE CONNECTORFUNCTION
1 AUX POWER OUT - 3.8 A 2-pin 0B LEMO Provides a combined 3.8 A max current out for 2-
pin based accessories when the module is
receiving power
2 DC IN 6-pin 1B LEMO Provides power to the camera system, the AUX
POWER OUT port, and an approximate 2 A charge
current to an attached REDVOLT XL battery
C OPYRI G HT © 2017 RED.C OM , LLC 955- 0038, REV-AD| 49
RED DSMC POWER OPERATION GUIDE

RED DSMC SIDE HANDLE Specifications

General

Brand	RED
Model	DSMC SIDE HANDLE
Category	Camera Accessories
Language	English
