RED BRICK CHARGER LED INDICATORS

COLOR PATTERN DESCRIPTION

Green Charger on, battery fully charged

Green/Amber flashing (alternating) Charger on, battery almost fully charged

Amber Charger on, battery connected and charging

Amber flashing Charger on, battery connected and charging

Red/Green flashing (alternating) Charger on, fail condition

Red Charger on, no battery connected

RECHARGE RED BRICKS

1. Connect the RED BRICK Charger to a 100–240 VAC, 50/60 Hz power outlet.

2. Turn on the RED BRICK Charger using the power switch.

3. Align and lower the RED BRICK or REDVOLT-V into the V-plate adaptor.

4. Charge the battery until the LED indicator turns green, signalling a fully charged battery.

5. Press the release tab and remove the battery by pulling it up and off of the RED BRICK Charger.

NOTE: When a 6-pin LEMO is connected to the auxiliary power output, the charging process is suspended. The

auxiliary LED illuminates and the battery LEDs on the charger flashes green. Once the cable is unplugged, the RED

BRICK Charger resumes charging.
