COPYRIGHT © 2014 RED.COM, INC
RED DSMC OPERATION GUIDE
955-0020_V5.1, REV-H | 130
WARNING: All lenses are hot swappable. However, lens mounts are NOT HOT SWAPPABLE, meaning you cannot
remove or install lens mounts while the camera is powered on. Before installing or removing lens mounts, you
MUST power down the camera. Failure to do so may result in damage to the lens mounts or DSMC that will
not be covered under warranty.
LENS WEIGHT AND LENS SUPPORT
Use a lens support system when mounting heavy or long lenses to your camera.
When mounting a heavy or long lens, ensure that the full weight of the lens is never directly on the camera or
lens mount. Mount the lens to the support system first, and then carefully mount the lens to the camera.
Due to the lightweight construction of the carbon fiber BRAIN and magnesium mounts, most setups with the
carbon fiber BRAIN will require a lens support system for all but the lightest lenses.
WARNING: Failure to use lens supports appropriate for the lens and camera setup may lead to damage of the
DSMC and lens mount. Any damage caused by not using a lens support system will not be covered under war-
ranty.
DSMC TI PL MOUNT SUPPORTED LENSES
The DSMC TI PL Mount is designed to work with most standard PL mount cinema lenses and devices.
WARNING: Using a non-standard PL mount lens or device with the DSMC TI PL Mount may lead to damage of
the DSMC and lens mount. Any damage caused by not using a standard PL mount lens or device will not be
covered under warranty.
DSMC CANON MOUNT SUPPORTED LENSES
The DSMC Canon Mount and DSMC Canon MOTION MOUNT electronically support the following lenses:
Canon EF 14mm f/2.8L II USM
Canon EF 15mm f/2.8 Fisheye
Canon EF 16-35mm f/2.8L II
Canon EF 17-40mm f/4L
Canon EF 20mm f/2.8 USM
Canon EF 24mm f/1.4L II
Canon EF 24mm f/2.8
Canon EF 24mm f/2.8 IS USM
Canon EF 24-70mm f/2.8L
Canon EF 24-70mm f/2.8L II USM
Canon EF 24-70mm f/4L IS USM
Canon EF 24-105mm f/4L IS
Canon EF 28mm f/1.8 USM
B
SUPPORTED
LENSES
