RED DSMC OPERATION GUIDE

955-0020_V5.1, REV-H | 46

The Advanced Menus include: Settings, Media, Playback, Power, HDR, Focus, and Presets.

You can access the Advanced Menus the following ways:

 Press the Menu button on the DSMC

SIDE HANDLE or REDMOTE.

 Press the Menu icon on the LCD.

 Go to any Basic Menu except the REDCODE menu, and select the Advanced... button to access the related

settings in the Advanced Menus. For example, if you open the Resolution menu and click Advanced, the

camera takes you directly to the Settings > Project > Format screen, where you can modify the resolution,

aspect ratio, anamorphic setting, and lookaround setting.

SETTINGS MENU

This section describes the various secondary controls available to configure the camera. Menu options are

Display, Look, Project, Audio, Recording, Setup, and Maintenance.

DISPLAY

Available options are Tools, Zebra, Monitor Control, Modes, Guides, and Test Signals.

TOOLS

The Tools menu allows you to use different false color modes and display modes. False color options are None,

Exposure, Focus, Video, and Edge. Display mode options are Magnify and RAW.

You can access the Tools menu the following ways:

 Navigate to Settings > Display > Tools.

 Press the Histogram in the lower left area of the on-screen display.

For more information about the different false color modes, check out the Exposure with RED Cameras: False

Color & Zebra Tools article available at www.red.com/learn/red-101/exposure-false-color-zebra-tools.

FALSE COLOR MODES

NOTE: Only monitors with the Tools check box selected in the Monitor Control screen will show the false colors.

For more information about monitor control, go to “Monitor Control” on page 48.

NOTE: When enabled, the false color modes will affect video that’s recorded through HDMI or HD-SDI out to

an external recorder when the Tools check box is selected. If you’re recording through HDMI or HD-SDI, RED

recommends using the false color modes only as tools to help you configure your project settings, and that you

disable these modes before you start recording.

NONE

Turns off all of the false color modes.

ADVANCED

MENUS
