COPYRIGHT © 2014 RED.COM, INC
RED DSMC OPERATION GUIDE
955-0020_V5.1, REV-H | 36
NOTE: For more information about powering the DSMC, see the DSMC Power Operation Guide available at www.
red.com/downloads.
NOTE: For more information about the Power menu, go to “Power Menu” on page 93.
POWER CONSUMPTION
The camera draws approximately 60 watts when recording in 5K resolution, at 24 FPS in MOVIE mode. The
camera is cooled by convection from the camera body assisted by a fan contained in a sealed air duct.
Under typical operating conditions, a REDVOLT
®
battery will run the camera and accessories for about 30 min-
utes and a REDVOLT
®
XL battery will run the camera and accessories for about 90 minutes.
POWER PRIORITY
When multiple power sources are available to the camera, power consumption is prioritized as follows:
1. DC power supply
2. Attached RED BRICK (Lowest % first)
3. Battery module batteries (Lowest % first)
4. REDVOLT battery in the DSMC SIDE HANDLE
POWER STATUS
The power status of each power source displays on the Power In screen. To view the Power In screen, go to
Menu > Power > Power In.
POWER UP
1. Attach a power source to the DSMC. For more information about the different power sources, go to “Power
Status” on page 36.
The Power Status LED illuminates red, indicating that an appropriate power source is connected.
2. Locate the Power/Record button on the right side of the DSMC BRAIN.
NOTE: The Power/Record button also serves as a Record Start/Stop button once the camera is powered up.
3. Press and release the Power/Record button.
The Power Status LED initially goes out, and within 5 seconds illuminates yellow to confirm the camera is
powering up.
The Power Status LED then illuminates green to confirm that the camera is powered up and ready to use.
NOTE: Once powered up, if the Power Status LED illuminates red AND is flashing, there is less than five minutes
of battery time left.
03
POWER THE
DSMC
