RED DSMC OPERATION GUIDE

955-0020_V5.1, REV-H | 35

TOUCHSCREEN LCD PRECAUTIONS

CAUTION: DO NOT use the threaded holes when mounting the LCD to the RED camera BRAIN. Doing so may

damage the camera or the display.

WARNING: DO NOT use the RED LCD as a handle to lift or carry the DSMC. Damage to the RED LCD or other

components of the DSMC system caused by using the RED LCD as a handle are not covered under warranty.

NOTE: The RED LCD swivel axis has a total range of adjustment of approximately 360˚ (180˚ clockwise or coun-

terclockwise from the nominal “rear-facing” display orientation). The range of adjustment for the tilt axis is ap-

proximately 180˚. At the end of the adjustment range are internal “hard stops” for both axes. Once the swivel

or tilt hard stops have been reached, IMMEDIATELY STOP APPLYING FORCE TO THE LCD. Continuing to

apply force after reaching the internal stops may damage the friction hinge. Damage to the RED LCD or other

components of the DSMC system caused by using excessive force to rotate the RED LCD is not covered under

warranty.

DO NOT Use Threaded Holes
