RED DSMC OPERATION GUIDE

955-0020_V5.1, REV-H | 31

REPLACE HOOD SCOOP

The hood scoop on some EPIC-X and EPIC-M models sweep back and extend beyond the rear plane of the

camera. Replacement hood scoops are available to allow for the attachment of an LCD display or other RED

accessories to the mounting locations on the top of the +1 ADAPTOR MODULE.

Use the following instructions to replace DSMC fan hood scoop.

1. Use a T8 Torx driver to remove the four (4) M3x0.5 x 6 mm cap screws holding the hood scoop.

2. Lift off the old hood scoop.

3. Place the replacement hood scoop on the camera. Align the hood scoop screw holes with the threaded

holes on top of the camera.

4. Attach the replacement top vent scoop to the DSMC BRAIN by installing the four (4) M3x0.5 x 6 mm cap

screws in a cross pattern with a T8 Torx driver. DO NOT FULLY TIGHTEN.

5. Tighten the M3x0.5 x 6 mm cap screws evenly. DO NOT exceed 30 in-oz, or damage may occur.

WARNING: DO NOT OVERTIGHTEN.

Replace the Hood Scoop
