COPYRIGHT © 2015 RED.COM, INC
RED DSMC OPERATION GUIDE: WEAPON
955-0116_V6.1, REV-H | 161
This appendix provides pinout information for the input/output connectors on the following expanders:
DSMC
2™
Base Expander
DSMC
2
REDVOLT Expander
DSMC
2
Jetpack Expander
NOTE: When connecting a cable to a connector, align the key and red marker on the cable connector with the
corresponding key and marker on the device connection.
NOTE: Connector diagram images are for reference only. Diagrams are not to scale.
B
INPUT/OUTPUT
CONNECTORS
