RED WEAPON 6K - DSMC 2 Jetpack Expander

COPYRIGHT © 2015 RED.COM, INC
RED DSMC OPERATION GUIDE: WEAPON
955-0116_V6.1, REV-H | 164
DSMC
2
JETPACK EXPANDER
NOTE: Detailed pinout information for the DSMC
2
Jetpack Expander is not currently published.
1
2
3
4
5
# CONNECTOR CONNECTOR TYPE
1 CTRL 4-pin 00B LEMO
2 HDMI Dongle Port HDMI
3 DC IN 6-pin 1B LEMO
4 SYNC 4-pin 00B LEMO
5 USB USB 2.0
DSMC
2
Jetpack Expander
