RED DSMC OPERATION GUIDE: WEAPON
COPYRIGHT © 2015 RED.COM, INC 955-0116_V6.1, REV-H | 169
AUDIO PORTS
STEREO MICROPHONE
The DSMC
2
Base Expander features a stereo microphone jack.
The 3.5mm stereo microphone provides two (2) channels of audio for recording.
HEADPHONE JACK
PIN SIGNAL DESCRIPTION DIRECTION
TIP LEFT Left channel audio In
RING RIGHT Right channel audio In
SLEEVE GND Camera ground N/A
HEADPHONE
The DSMC
2
Base Expander features a headphone jack.
The 3.5mm stereo jack provides two (2) channels of audio for monitoring. For maximum quality, use high
impedance headphones.
HEADPHONE JACK
PIN SIGNAL DESCRIPTION DIRECTION
TIP LEFT Left channel audio Out
RING RIGHT Right channel audio Out
SLEEVE GND Camera ground N/A
