RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W
COPYRIGHT © 2016 RED.COM, INC 955-0116_V6.1, REV-U | 21
DSMC
2
JETPACK EXPANDER
The DSMC
2
Jetpack Expander is specifically designed for aerial, gimbal, handheld, and other lightweight/
remote configurations. This expander features standard connectors for power (DC-IN), CTRL, and SYNC for all
of your Timecode and Genlock needs. In addition, the DSMC
2
Jetpack Expander offers custom-tailored support
and connectors for HDMI and USB power out—perfect for housings and low-profile setups.
The DSMC
2
Jetpack Expander also features a selector switch that enables the camera to automatically boot
when power is provided via the DC IN connector on the expander. This feature allows you to use a connected
DC input supply to turn the camera on and off when the camera is mounted in remote or difficult to maneuver
locations.
NOTE: Only one (1) expander module can be used at a time.
DSMC
2
Jetpack Expander
