COPYRIGHT © 2016 RED.COM, INC
RED DSMC OPERATION GUIDE: WEAPON/SCARLET-W
955-0116_V6.1, REV-U | 22
DSMC
2
BASE I/O V-LOCK EXPANDER
The DSMC
2
™ Base I/O V-Lock Expander offers a variety of Input/Output connections, as well as an industry
standard V-Lock mount to power your WEAPON, SCARLET-W, or RED RAVEN™ camera using RED BRICK
batteries.
The DSMC
2
Base I/O V-Lock Expander also features a selector switch that enables the BRAIN to automatically
boot when power is provided via the DC IN connector on the expander. This feature allows you to use a
connected DC input supply to turn the BRAIN on and off when the camera is mounted in remote or difficult to
maneuver locations.
This expander is an ideal solution for a wide variety of production environments—from low-profile run-and-gun
situations to studio shoots that require mobility.
NOTE: The DSMC
2
Top Handle may not be fully compatible with the DSMC
2
Base I/O V-Lock Expander, as the
top handle will interfere with the battery when one is attached to the expander module.
NOTE: Only one (1) expander module can be used at a time.
DSMC
2
Base I/O V-Lock
Expander
