12 | E33-10 FPI Direct Vent Gas Insert
|
12
installation
SPECIFICATIONS
At pressures over 1/2 psig, the pipe to the unit
must be disconnected.
Gas Input Capacity:
Natural Gas 38,000 Btu/h
Propane 35,500 Btu/h
Min. Input:
Natural Gas 20,000 Btu/h
Propane 19,000 Btu/h
Fuels: Approved for use with both natural gas,
and propane. Approved as is for use at 0' to 4,500'
(0-1370m).
Electrical: 120V A.C. system.
Circulation Fan: Variable speed, 127 CFM.
Log Set: Ceramic bre, 8 per set.
Vent System: 3" co-linear aluminum ex.
INSTALLATION
CHECKLIST
Before installing vent system ensure that the damper
plate is open and secure to prevent the damper plate
from falling down and crushing the liner.
The Regency Gas Insert is installed as listed below.
1) Check all clearances to combustibles. Refer
to the following sections where applicable:
a. Minimum Clearances to Combustibles.
b. Combustible Mantel Clearances
2) Make the gas connection. Refer to the "Gas
Connection" section.
3) Install the 3" ue liner to the sliding connector
plate. Refer to the "Flue Liner Installation"
section.
4) Slide the unit half way into the replace.
5) Pull the vent connector plate through the tapered
brackets and fasten to the front plate. Refer to
the "Flue Liner Installation" section.
6) Slide the unit fully into the replace.
7) Install 4 AA batteries into receiver. Hook
receiver to wire marked receiver, this will enable
operation of the appliance manually when
position in "ON" position.
8) Test gas pressure, refer to the "Gas Pipe
Pressure Testing" section. Check aeration
system, refer to "Gas Insert Aeration System"
section.
9) Install standard and optional features. Refer
to the following sections where applicable:
a. Brick Panels
b. Log Installation
c. Faceplate
d. Standard Flush Door
e. Remote Control
10) Final check. Refer to the "Operating
Instructions" section. Before leaving this unit
with the customer, the installer must ensure that
the appliance is ring correctly. This includes:
a) Clocking the appliance to ensure the
correct ring rate.
b) Adjusting the primary air, if required, to
ensure that the ame does not carbon.
Refer to the "Gas Insert Aeration
System" section.
c) Ensuring that the appliance is venting
correctly.
MATERIALS
REQUIRED
No electrical power supply is required for the gas
control to operate. A 120 Volt AC power cord is
hooked up to the fan. Plug the 3 wire cord into
a suitable receptacle. Do not cut the ground
terminal o under any circumstances. When
connected with 120 volts, the appliance must be
electrically grounded in accordance with local
codes, or in the absence of local codes, with current
version of the Canadian Electrical Code CSA C22.1
(in Canada) or with the National Electrical Code
ANSI/NFPA 70.
NOTE: This unit is equipped with a heat sensor
thermodisc which will prevent the blower from
operating until the unit reaches the correct
temperature.
