Regency Ultimate U1500E-LP - Parts; Parts List; Main Assembly

56 | Regency Ultimate
™
U1500E Gas Fireplace
parts list
MAIN ASSEMBLY
1 676-574/P Valve Assembly - NG
1 676-576/P Valve Assembly - LP
2 911-084 Novasit Valve NG 885 SIT IPI 0.885.001
2 911-085 Novasit Valve LP 885 SIT IPI 0.885.002
3 904-660 Burner Orifice #30 NG
3 904-622 Burner Orifice #48 LP
4 911-006 Pilot Assembly IPI NG 2 Flame 0.199.050
4 911-007 Pilot Assembly IPI LP 2 Flame
5 910-100 Pilot Orifice NG #51 0.977.166
6 910-101 Pilot Orifice LP #35 0.977.168
7 911-039 Two Way Pilot Hood 0.975.005
8 911-037 Flame Sense 0.915.905
9 911-038 Flame Electrode 0.915.020
10 910-432 Pilot Tube with Nuts
11 911-010 Stepper Motor NG 0.907.013
11 911-011 Stepper Motor LP 0.907.012
12 606-054 Pilot Hood
13 606-028 Valve Mounting Gasket
14 676-530 Ceramic Burner Assembly NG/LP
15 606-008 Left Ceramic Mounting Bracket
16 606-009 Right Ceramic Mounting Bracket
17 606-514 Door Frame Assembly - Complete
18 940-431/P Replacement Glass ( Includes Gasket)
19 606-017 Flush Door Frame Only (No Glass)
20 396-527 Door Latch Assembly
21 676-012F Top Relief Door (Each)
22 676-032 Top Relief Door Gasket (Each)
23 904-841 Top Relief Door Bolts (Each)
24 676-011 Top Relief Door Frame (Each)
25 676-031 Top Relief Door Gasket (Each)
26 676-023 Enamel Black Panel Left
27 676-024 Enamel Black Panel Right
28 466-041F Nailing Strip Sides (Each)
29 696-045 Deflector Front
30 676-030 Rear Log Tray
31 676-025 Enamel Panel Clips (Each)
32 676-922 Inner Door Frame Black U1500E
32 676-926 Inner Door Frame Gloss Black U1500E
N/S = Not Shown
N/S 932-009 Tubing SS Flexible 3/8 x 9 inch
N/S 904-599 Fitting Elbow 90 Degree
N/S 904-911 Fitting Connector 1/2 MIP x 1/2 Flare
N/S 904-600 Fitting Elbow 90 Degree Forged
N/S 904-650 Fitting 1/8 Brass Pipe Adaptor
N/S 904-658 Inlet Flex Line Gas SS Steel 24 inch
N/S 936-170 Gasket Burner Orifice
N/S W840470 Gasket Pilot Assembly
N/S 606-029F Valve/Fan Access Plate
N/S 606-030 Valve/Fan Access Plate Gasket
N/S 466-025F Front Access Panel
N/S 606-063 Left Ceramic Filler (Burner)
N/S 606-064 Right Ceramic Filler (Burner)
N/S 911-173 Wire Harness IFC No CPI Switch 584.924
N/S 911-174 IFC Control Board Complete 584.306
N/S 911-177 Wire 4 Position IFC Fan & Light
N/S 911-181 Wire Harness Battery Box Proflame II
N/S 911-192 Power Cord 120 Volts With Connector
N/S 911-193 Connector With Jumper
N/S 911-175 Hand Held Remote Control GTMFL SIT
0.584.042
N/S 911-187 Battery Holder With Switch 584.103
N/S 910-369 Receptacle Box Low Voltage
N/S 910-576 Cover Wall Mount White GTM SIT
0.584.803
N/S 910-428 Receptacle Duplex White
N/S 910-429 Receptacle Box Duplex Metal
N/S 904-687 Connector Clamp 3/8 CI-804
N/S 936-157 Glass Gasket Tadpole Tape 1 1/2 (Sold
Per Foot) (9 Feet required)
N/S 904-691 Glass Clip-U (Each)
N/S 396-042F Door Tool
N/S 606-930 Log Set - Complete
N/S 636-517/P Fan Assembly Complete
N/S 910-157/P Fan Motor Only (Includes Squirrel Cage)
N/S 908-529 Label Natural Gas Yellow
N/S 908-528 Label Propane Red
N/S 466-025F Access Panel
N/S 676-001 Top Nailing Strip
N/S 316-089F Bottom Nailing Strip
N/S 676-021 Top Inner Baffle
N/S 676-033F Vent Restrictor
N/S 636-022 Heat Shield Control Box
N/S 636-550 Horizontal Vent Deflector Complete
N/S 919-792 Instruction Manual
N/S 676-507 Manual Package Complete
