3.2.2 The REHM control panel
The plasma cutting equipment is operated using the REHM control panel shown
in Fig. 3.1.
Figure 3.1 Control panel on the BARRACUDA RTC 150 (RTC 60 and RTC 100
layouts are similar)
The control panel is divided into the following areas:
 Measuring instruments for the compressed air setting
 Cutting current selection knob
 Rotary knob for compressed air setting
 Control lamps
 Function selection switch 2-step, 4-step, gas test
730 0178
1,
2
40
50
60
70
80
90
100
110
120
130
140
150
30
25
60
50
40
30
25
R145
A80
5,0-5,5 BAR ( A80 / R145 )
72,5-79,75 psi
150
