CHILD SEATS
2
94 - Getting to know your vehicle
Installation table
The table below summarises the information already shown on the previous diagram in order to ensure the regulations
in force are respected.
2-seater van version Front passenger seat
Child seat group Weight of the child Passenger Airbag activated Without passenger airbag or deactivated
Rear-facing shell seat
Group 0 or 0 +
< 13 kg X U (1) (2)
Rear-facing seat
Group 0+ and 1
< 13 kg and
9 to 18 kg
X U (1) (2)
Forward-facing seat
Group 1
9 to 18 kg U (2) X
Booster seat
Group 2 and 3
15 kg to 25 kg and
22 to 36 kg
U/B2 (2) X
U = Seat enabling a child seat with "Universal" approval to be attached by seat belt: check that it can be fitted.
B2 = Seat allowing a child seat with "B2" approval to be attached by seat belt: check that it can be fitted.
RISK OF DEATH OR SERIOUS INJURY, before installing a child seat:
(1) on the front passenger seat, check that the airbag has been deactivated 🡺116;
(2) position the vehicle seat as far back and as high as possible. Tilt the seatback slightly 🡺63. Adjust the seat
belt position to the lowest position. After you have adjusted it, make sure that the seat belt is locked in position
correctly 🡺68.
