5.2.2 Hall sensor signal input
This product has connector for hall sensor signal input. Pin assignment of it is listed in Table 5-7.
Table 5-7 Connector for hall sensor signal input (CN6) pin assignment
Pin No.
Pin Function
1
DGND
2
+5V
3
HALL_W
4
HALL_V
5
HALL_U
5.2.3 Encoder/Inductive position sensor signal input
This product has pins for encoder/inductive position sensor signal input. Pin assignment for them is listed in
Table 5-8
Table 5-8 Pins for encoder/inductive position sensor signal input (CN7) pin assignment
Pin No.
Pin function
1
VCC
2
+5V
3
CSN_IRQN/ENC_Z
4
SIO_SDA
5
SCK_SCL
6
IPS_A/ENC_A
7
IPS_A#/ENC_A#
8
IPS_B/ENC_B
9
IPS_B#/ENC_B#
10
DGND
