Renesas RA6 Series - Led; CAN Communication; SPI Communication

Renesas RA Family MCK-RA6T2 User's Manual
R12UZ0091EJ0100 Rev 1.00 Page 32 of 38
August 3, 2021
6.1.6 LED
This product has six ports and LEDs, so that they can be used for program debug and the system. LED
switches on when output from the corresponding port is “LOW” and switches off when output is “HIGH”. Pin
assignment for corresponding LEDs is listed in Table 6-6.
Table 6-6 LED pin assignment
RA6T2 port
LED1
LED2
LED3
LED4
LED5
LED6
PD01
Output HIGH
OFF
-
-
-
-
-
Output LOW
ON
-
-
-
-
-
PD02
Output HIGH
-
OFF
-
-
-
-
Output LOW
-
ON
-
-
-
-
PD03
Output HIGH
-
-
OFF
-
-
-
Output LOW
-
-
ON
-
-
-
PD15
Output HIGH
-
-
-
OFF
-
-
Output LOW
-
-
-
ON
-
-
PC06
Output HIGH
-
-
-
-
OFF
-
Output LOW
-
-
-
-
ON
-
PC07
Output HIGH
-
-
-
-
-
OFF
Output LOW
-
-
-
-
-
ON
6.1.7 CAN Communication
This product has through holes for CAN communication. Note that CAN driver is not equipped. Pin
assignment for CAN communication connector is listed in Table 6-7.
Table 6-7 CAN communication pin assignment (CN8)
Pin No
RA6T2 pin
1
VCC
2
PB13/CTX0_E
3
PB12/CRX0_E
4
VSS
6.1.8 SPI communication
This product has through holes for SPI communication. Pin Assignment for SPI communication connector is
listed in Table 6-8.
Table 6-8 SPI communication pin assignment (CN9)
Pin No
RA6T2 pin
1
PD00_SS0
2
PC12_MOSI0
3
PC11_MISO0/SIO_SDA
4
PC10_SCK0/SCK_SCL
5
VSS
6
VCC
