6.2 RA6T2 pin function list
Table 6-9 RA6T2 pin function list
Pin number
RA6T2 pin function
Signal function
1
PE02/TRCLK/CMPOUT0_C/GTOVLO_C/GTIOC7B_B/GTIOC8A_E/GT
CPPO8/SCK0_B/DE0_D/SCK3_A/DE3_A/RSPCKB_C/CLKOUT_C
ARM debugger
2
PE03/TRDATA0/CMPOUT1_C/GTOWLO_C/GTIOC8A_B/GTIOC9A_E/
GTCPPO6/RXD0_B/CTS3_A/SSLB0_C/GTODFMA
ARM debugger
3
PE04/TRDATA1/CMPOUT2_C/GTOUUP_C/GTIOC8B_B/GTIOC7B_E/
GTCPPO9/TXD0_B/SS_CTS_RTS3_A/DE3_A/SSLB1_C/GTODFMB
ARM debugger
4
PE05/TRDATA2/CMPOUT3_C/GTOVUP_C/GTIOC9A_B/GTIOC8B_E/
GTCPPO2/SS_CTS_RTS0_B/DE0_B/RXD3_A/MISOB_C/GTODFMC
ARM debugger
5
PE06/TRDATA3/GTOWUP_C/GTIOC9B_B/GTCPPO3/CTS0_B/TXD3_
A/MOSIB_C/GTODFMD
ARM debugger
6
VCC
Power
7
PC13/GTETRGD/NMI
INV1 over current
8
PC14/ADTRG0_C/CMPOUT012_B/AGTWIO0_C/GTETRGA/GTIOC3A
_D/GTCPPO0/GTADSM0/GTCPPO4/IRQ14_A/GTODFMC
INV1 Encoder_A
9
PC15/ADTRG1_C/CMPOUT345_B/AGTWIO1_C/GTETRGB/GTIOC3B
_D/GTCPPO1/GTADSM1/GTCPPO7/IRQ15_A/GTODFMD
INV1 Encoder_B
10
VSS
Power
11
VCC
Power
12
P212/EXTAL
Xtal
13
P213/XTAL/IRQ0_C
Xtal
14
RES
ARM debugger
15
PC00/AN012 (AN012)/PGAOUT0/IVCMP00/IRQ11DS
INV2 SW1
16
PC01/AN013 (AN013)/PGAOUT1/IVCMP10/IRQ12DS
INV2 SW2
17
PC02/AN014 (AN014)/PGAOUT2/IVCMP20/IRQ13DS
INV2 PFC current
detection/IPS_A
18
PC03/AN015 (AN015)/PGAOUT3/IVCMP30/IRQ14DS
INV2 PFC current
detection/IPS_A #
19
P000/AN016 (AN016)/IVREF0/IRQ0_D
INV2 PFC over current
detection
20
VREFL0
Power
21
VREFH0
Power
22
P001/AN017 (AN017)/IVREF1/IRQ2_C
INV1 PFC over current
detection
23
PA00/AN000 (AN000)/PGAIN0/IVCMP02 / IVCMP03/IRQ0DS
INV1 W-phase current
detection
24
PA01/AN001 (AN001)/PGAVSS0/IRQ1_A
INV1 W-phase voltage
detection/PGAVSS_
W
25
PA02/AN002 (AN002)/PGAIN1/IVCMP12 / IVCMP13/IRQ2_A
INV1 V-phase current
detection
26
PA03/AN003 (AN003)/PGAVSS1/IRQ3_A
INV1 V-phase voltage
detection/PGAVSS_
V
27
AVSS0
Power
28
AVCC0
Power
29
PA04/AN004 (AN004)/PGAIN2/IVCMP22 / IVCMP23/IRQ4_A
INV1 U-phase current
detection
30
PA05/AN005 (AN005)/PGAVSS2/IRQ5_A
INV1 PGAVSS_U
31
PA06/AN006 (AN106)/DA0/IRQ6_A
INV1 bus voltage
detection
32
PA07/AN007 (AN107)/DA1/IRQ7_A
INV1 W-phase voltage
detection
33
PC04/AN010 (AN110)/DA2/IRQ10_B
INV1 HALL_U/IPS_A
34
PC05/AN011 (AN111)/DA3/IRQ11_B
INV1 HALL_V/IPS_A#
35
PB00/AN008 (AN108)/PGAOUT0 / PGAOUT2/IRQ0_A
INV1 VR1 voltage
detection
36
PB01/AN009 (AN109)/PGAOUT1 / PGAOUT3/IRQ1_B
INV1 HALL_W
