TPS-1 User’s Manual: Hardware 4. Shared memory structure
R19UH0081ED0107 Rev. 1.07 page 40 of 86
Jul 30, 2018
Table 4-5: Register PN_Event_high
Name
PN_Event_high
Address 0x0040
Access
r/ w
Bits Type of Event Description Init:
31:00
Event-Bit
(Stack Events)
high active events
Bit 0: TPS_EVENT_ONCONNECTDONE_IOAR0
Bit 1: TPS_EVENT_ONCONNECTDONE_IOAR1
Bit 2: TPS_EVENT_ONCONNECTDONE_IOSAR
Bit 3: TPS_EVENT_ON_PRM_END_DONE_IOAR0
Bit 4: TPS_EVENT_ON_PRM_END_DONE_IOAR1
Bit 5: TPS_EVENT_ON_PRM_END_DONE_IOSAR
Bit 6: TPS_EVENT_ONABORT_IOAR0
Bit 7: TPS_EVENT_ONABORT_IOAR1
Bit 8: TPS_EVENT_ONABORT_IOSAR
Bit 9: TPS_EVENT_ONREADRECORD
Bit 10:
TPS_EVENT_ONWRITERECORD
Bit 11: TPS_EVENT_ONALARM_ACK_0
Bit 12: TPS_EVENT_ONDIAG_ACK
Bit 13: TPS_EVENT_ONCONNECT_REQ_REC_0
Bit 14: TPS_EVENT_ONCONNECT_REQ_REC_1
Bit 15: TPS_EVENT_ONCONNECT_REQ_REC_2
Bit 16: TPS_EVENT_ON_SET_DEVNAME
Bit 17: TPS_EVENT_ON_SET_IP_PERM
Bit 18: TPS_EVENT_ON_SET_IP_TEMP
Bit 19: TPS_EVENT_ONDCP_BLINK_START
Bit 20: TPS_EVENT_ONDCP_FACTORY_RESET
Bit 21: TPS_EVENT_ONALARM_ACK_1
Bit 22: TPS_EVENT_RESET
Bit 23: TPS_EVENT_ETH_FRAME_REC
Bit 24: TPS_EVENT_TPS_MESSAGE
Bit 25 - 26: For internal use only
Bit 27: TPS_EVENT_ON_LED_STATE_CHANGE
Bit 28: TPS_EVENT_ON_SET_DEVNAME_PERM
Bit 29: TPS_EVENT_ON_FSUDATA_CHANGE
Bit 30 – 31: reserved for further use
0X00000000
