Renishaw NC4 Installation Guide

6-2
NC4 non-contact tool setting system: Parts list
NC4 separates installation pack, supplied with:
• NC4 separates unit pack
• NCi-6 interface unit
• Air preparation pack for barrier air (standard)
• Ø3.0 mm (0.12 in) tube installation pack × 5.0 m (16.40 ft)
• Ø4.0 mm (0.16 in) x 20 m (65.62 ft) air tube
• Ø4.0 mm (0.16 in) tube installation pack × 5.0 m (16.40 ft)
• Pneumatic ttings
• Conduit pack (GP11) – 4.0 m (13.12 ft)
• NC4 tools
Item Part number Description
NC4 0.3 m to 0.5 m
separation pack
A-4114-5055 NC4 0.3 m to 0.5 m separation pack, including NC4 Tx unit
(access panel with 20 identication marking) and NC4 Rx unit
(access panel with 40 identication marking).
NC4 0.5 m to 0.8 m
separation pack
A-4114-5060 NC4 0.5 m to 0.8 m separation pack, including NC4 Tx unit
(access panel with 40 identication marking) and NC4 Rx unit
(access panel with 20 identication marking).
NC4 0.8 to 1.5 m
separation pack
A-4114-5065 NC4 0.8 m to 1.5 m separation pack, including NC4 Tx unit
(access panel with 40 identication marking) and NC4 Rx unit
(access panel with 40 identication marking).
NC4 1.5 m to 2.0 m
separation pack
A-4114-5070 NC4 1.5 m to 2.0 m separation pack, including NC4 Tx unit
(access panel with 40 identication marking) and NC4 Rx unit
(access panel with 60 identication marking).
NC4 2.0 to 3.0 m
separation pack
A-4114-5075 NC4 2.0 m to 3.0 m separation pack, including NC4 Tx unit
(access panel with 60 identication marking) and NC4 Rx unit
(access panel with 40 identication marking).
NC4 3.0 to 5.0 m
separation pack
A-4114-5080 NC4 3.0 m to 5.0 m separation pack, including NC4 Tx unit
(access panel with 60 identication marking) and NC4 Rx unit
(access panel with 60 identication marking)
