3.2.3 • Screwing the side guiding channels into place
Mounting of side guiding
channel ‘G’ through the
backside (Ø5mm)
35
110 110
4862 4862
35 35 35
110
35
110
35
110
35
35
6248 6248
35
Mounting of side guiding
channel ‘D’ through the
backside (Ø5mm)
Mounting of coupling side
guiding channel ‘K’ through
the backside
Mounting of side guiding
channel ‘D’ sideways
(Ø5mm)
ø5
ø10
Mounting of side guiding
channel ‘G’ sideways
(Ø5mm)
Attention: To be able to
disassemble the fabric set
from beneath, the client must
foresee something under-
neath the head box that can
be dismantled when choos-
ing the narrow side guiding
channel G.
