Reolink C1 User Manual

40
Please refer to 4.2.1 Record > Encode.
5.3 Basic Settings > Image
You can adjust the picture for live feed under this menu.
 Brightness: Changes how light the image appears to be.
 Contrast: Increases the difference between the blackest black and the whitest white
in the image.
 Saturation: Alters how much color is displayed in the image. The higher the saturation,
the brighter and more vivid colors will appear to be.
 Hue: Changes the color mix of the image (this can have very dramatic results).
 Sharpen: Sharpen image to increase the Signal Noise Ratio.
 Mirroring: Choose to change the orientation of the image to
be horizontally reversed.

Reolink C1 Specifications

General

Frame Rate	20fps
Image Sensor	1/2.7" CMOS
Wireless Standard	IEEE 802.11b/g/n
Operating Frequency	2.4GHz
Wireless Security	WPA/WPA2
Protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Storage	Micro SD card (up to 128GB)
Operating Temperature	-10° C~+55° C (14° F~131° F)

Summary

Chapter 1 General Introduction of the camera

1.1 Product Feature

Details camera specifications including sensor, resolution, lens, angle of view, IR distance, dimensions, weight, power input, and interface.

Chapter 2 Install Reolink Client software

2.1 Connection Diagram

Illustrates the connection steps between the camera, router, and computer for initial setup.

2.2 Requirement for computer

Lists the necessary hardware and operating system requirements for installing the Reolink client software.

2.3 Installing process

Provides a step-by-step guide for installing the Reolink client software on a computer, including wizard steps.

Chapter 3 Overview of client software

3.1 Live View

Chapter 4 Camera Configuration

4.2 Device Settings > Recording

Covers parameters for recording, including stream type, resolution, frame rate, bitrate, and recording options for the SD card.

4.3 Device Settings > Network

4.4 Device Settings > Alarm

Chapter 5 Basic Settings
