Reolink C1 User Manual

1
Chapter 1 General Introduction of the camera
1.1 Product Feature
Model
C1
Hardware
Features
Image Sensor
1/2.7" CMOS Sensor
Display Resolution
1920 x 1080 (2.0Megapixel)
Lens
f=2.8-8mm Autofocus, F=1.6, With
IRCUT
Angle of View
Horizontal: 55° ~ 105°
Vertical: 30° ~ 58°
Pan/Tilt Angle
Horizontal: 355°
Vertical: 105°
Minimum Illumination
0 Lux (With IR Illuminator)
IR Distance
8 Meters (8pcs LED)
Dimensions
103 × 95 × 117mm
Weight
300g
Power Input
5V/2A, <6W
Interface
One 10M/100Mbps RJ45
Power Interface
Built-in Micro SD socket
Built-in Microphone and speaker
Reset Button
Software
Features
Protocols & Standards
TCP/IP, UDP/IP, DHCP, FTP, SMTP,
DDNS, NTP, UPnP, HTTP,P2P
Image Compression
H.264/MJPEG
Maximal Frame Rate
30fps
Code rate
1024Kbps ~ 6144Kbps
Audio
Two-way Audio
Maximum User Access
2 Users for Clear Stream
Browser Supported
IE, Edge, Chrome, Firefox, Safari
OS Supported
PC: Windows, Mac OS
Smart Phone: iOS, Android
Wireless
Features
Wireless Standard
IEEE 802.11a/b/g/n
Operating Frequency
2.4GHz / 5GHz
Wireless Security
WPA-PSK/WPA2-PSK
Other
parameters
Temperature
Operating Temperature: -10℃~+55℃
Storage Temperature: -40℃ ~ 70℃
Humidity
Operating Humidity: 20% ~ 85%
Storage Humidity: 10% ~ 90%
Waterproof
No

Reolink C1 Specifications

General

Frame Rate	20fps
Image Sensor	1/2.7" CMOS
Wireless Standard	IEEE 802.11b/g/n
Operating Frequency	2.4GHz
Wireless Security	WPA/WPA2
Protocols	HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Storage	Micro SD card (up to 128GB)
Operating Temperature	-10° C~+55° C (14° F~131° F)
