Retsch RS 200 - Replacing Wearing Parts

Cleaning, Wear and Maintenance
44
Fig.
34
: Positions of the rubber springs
• After servicing the rubber springs, insert the bottom cover.
• Secure the bottom cover using the two cylinder head bolts.
7.4 Wearing parts
Fig.
35
: Rubber springs
• Replace the 3 rubber springs (GF) after approx. 500 operating hours.
– Order No. 03.228.0003
Fig.
36
: Rubber pad
• Replace the rubber pad (GP) after approx. 300 operating hours.
– Order No. 03.243.0069
GF
GP
GF
