3 609 929 B45/2013-06 |
CS351/CC-CS351 Bosch Rexroth AG 89
/108
Commissioning
ENGLISH
9. Connect the hand-held nutrunner/tight-
ening spindle:
10. Connect the power supply connection
cable. The user is responsible for comply-
ing with the regulations for the power
supply connection.
11. Switch the Compact System on at the
power switch.
Additional steps may be necessary, depend-
ing on the Compact System variant.
CC variant: Setting the MCE factor
Variants with integrated computer unit:
Configuring the computer unit
CC variant: Setting the MCE factor
The nutrunner does not have to be adjusted
to the particular case of application if the
working range of the nominal torque is >40%
and the cycle time is >10 sec.
If the corresponding values are different, ad-
just as follows:
1. Set the operating temperature of the CC-
ErgoSpin to its future value.
2. Connect the BS350 CC-ES operating
program to the compact system.
3. Then perform several tightening opera-
tions (e.g. 10) at the desired working
point of the tightening case.
While doing so, determine the difference
of the measurement value shown on the
CC compact system from the reference
measurement value at the output drive of
the CC-ErgoSpin for each tightening
operation.
4. When using the BS350 CC-ES
operating program, determine the MCE
factor and enter it in the CC-ErgoSpin
component of the tightening channel
configuration as "MCE factor".
The MCE factor is determined as follows:
MCE factor = T
ref
/ T
set
T
ref
= reference torque
T
set
= set torque
Variants with integrated computer unit:
Configuring the computer unit
The integrated computer unit already has an
activated pre-installed Windows 7 operating
system.
After the CS351 Compact System has been
switched on, the integrated computer unit is
started automatically and Windows 7 is
opened.
To ensure that the controller of the Compact
System can communicate with the integrated
computer unit, the following steps must be
carried out on commissioning:
Configure the integrated computer unit in
slot B2 in the BS350 operating program of
the Compact System.
Configure the connection to the Compact
System via the Windows Control Panel of
the computer unit.
For information about controlling the BS350
operating program, refer to the online help
and to the system documentation on the en-
closed USB system stick.
The computer unit can only be
commissioned/configured while a
hand-held nutrunner or tightening
spindle is connected.
CS351_zweispaltig - D.book Seite 89 Dienstag, 16. Juli 2013 12:00 12
