6. System Setup and Operation
How to Achieve Multiple Cascade
VSP 516S User Manual 112
How to Achieve Multiple Cascade
The working principle of VSP 516S multiple cascade is assigned the front
signal to corresponding VSP 516S video processors, again synchronous
external timing through processor, and wholly enlarge the picture and
intercept corresponding display area according to the corresponding
control area to achieve the function of integral display a complete picture,
through the central control or computer, it can realize the synchronous
broadcasting and at the same time seamless switching.
Here, we will illustrate the operation. For example, the LED display is
2400 * 1024, and now we will cascade with 2 pieces of VSP 516S, specific
steps are as follows:
1. Connection and Setting
(1) Connect the DVI signal to DVI interface of the two VSP 516S through
DVI distributor (DXP 0108).
(2) Divide the LED display into two parts, respectively for 1152*1024 and
1248*1024, and connect the DVI output interface of the two VSP 516S
to two sending cards.
(3) Choose DVI input signal for the two VSP 516S, and set both the
VSP 516S output resolution for 1280 * 1024.
2. Multiple Cascade
(1) Push the [SCALE/CROP] button of the first VSP 516S, and scale the
screen to the actual points.
Choose <H SIZE> in menu option, and set the width as 1152 by the
knob or number button, push the knob to confirm.
Turn the knob, and choose <V SIZE> in menu option, and set the
height as 1024 by the knob or number button, push the knob to
confirm. If input the wrong value, push [MENU/EFFECT] button to exit.
The same method, set the width and height of the second VSP 516S
To Next Page
