4. Menu Orientation
MENU
VSP 516S User Manual 54
Note: On behalf of the image emerging;
On behalf of the image disappearing;
Arrows represents the direction of the image move, that is, the image that
arrow point, is compressed or stretched to the direction that arrow indicates,
until disappear or full screen.
FADE TIME: Switch time setting. Turn the knob to choose the time and
push the knob to confirm. The switching time ranges from 0 to1.0.
ALPHA: Image transparency setting, the regulating range is among 0 to
16.
DEINTERLACE: Force Deinterlace function, can choose ―ON‖ or ―OFF‖.
ON: Force interlace for interlaced signal without effect switching, but with
effects switching for progressive signal.
OFF: No deinterlace, with effect switching.
AUDIO
MUTE: Mute, can open or close the mute function.
VOLUME: Volume adjustment.
AUDIO IN: Can choose audio input source for IMAGE A or IMAGE B.
HDMI: Choose internal or external audio for HMDI.
SPLIT
Choose [SPLIT], push the knob to confirm, the OLED display show the
level 2 menu as following:
SPLIT ON/OFF: Split function, can choose ―ON‖ or ―OFF‖.
H TOTAL: The total width points of LED display that will split.
V TOTAL: The total height points of LED display that will split.
H POS: The horizontal position of the device when do split.
V POS: The vertical position of the device when do split.
H SIZE: The width of the device when do split
To Next Page
