RGBlink VSP 516S User Manual

VSP 516S User Manual 120
A. Specification
BNC Input
Number of Inputs
3
Supported Standards
PAL/NTSC
Signal Level
1Vpp±3db (0.7V Video+0.3v Sync ) 75 ohm
Multiplex
480i,576i
S-Video Input
Number of Inputs
1
Supported Standard
PAL/NTSC
Signal Level
Y:1Vpp±3dB (0.7V Video+0.3v Sync ) 75 ohm
U/V:0.7Vpp±3dB 75ohm
Multiplex
480i,576i
YPbPr BNC Input
Number of Inputs
BNC*3
Supported Standard
analog signals
Signal Level
Y:1Vpp±3dB(0.7V Video+0.3v Sync )75 ohm
Pb/Pr:0.7Vpp±3dB 75 ohm
Supported Resolution
480i,576i,480p,576p,720p50,1080i50,1080p50
1080i50,1080i60
VGA DB15 Input
Number of Inputs
1
Connector
Standard DB15 Socket
Supported Standard
VGA-UXGA
Signal Level
R、G、B、Hsync、Vsync:0 to1Vpp±3dB (0.7V Video+0.3v
Sync ) 75 ohm
black level: 300mV Sync-tip：0V
Supported Resolution
1024×768×60, 800×600×60, 640×480×60,
1280×720×60, 1280×800×60, 1280×960×60,
1280×1024×60, 1440×900×60, 1400×1050×60,
1600×1200×60, 1680×1050×60, 1920×1080×60,
1366×768×60
DVI Input
Number of Outputs
1
Connector
Standard DVI-I socket
Supported Resolution
SMPTE：625/25 PAL, 525/29.97 NTSC, 625/50p PAL,
525/59.94p NTSC
720p50,720p59.94/60,1080i50,1080i59.94/60
VESA：800×600×60Hz，1024×768×60Hz，
1280×768×60Hz，1280×1024×60Hz，
1600×1200×60Hz, 1920×1080×60Hz,
