4. Menu Orientation

VSP 516S User Manual 45

V UP--image to up zoom.

V DOWN--image to down zoom.

V UP/DOWN--image to up and down zoom.

H LEFT--image to left zoom.

H RIGHT--image to right zoom.

H LIFT/RIGHT--image to left and right zoom.

CENTER--image from center to the edges zoom.

RESET: If image quality distorts by improper operation, it can be recover by

reset.

For details, please refer to the instructions in the manual: How to Set up

Image Zoom.

VGA ADJUST：Adjust VGA input signal, sub menu as follows:

H POS: Image horizontal position.

V POS: Image vertical position.

CLOCK: Input signal clock.

PHASE: Input image phase.

Note

Only comments to professional operator.

AUTO ADJUST: Auto adjust VGA input signal H POS, V POS, CLOCK,

PHASE, auto adjust to display in full screen image.

Note

Comments customers to use this operation in

adjusting the VGA input shiftment.

ADC AUTO ADJUST：Mainly for brightness auto adjusting.

SDI ADJUST: When SDI input signal image shift, please adjust image’s H

POS and V POS to display in full screen image.

Sub menu as follows:
