4. Menu Orientation

VSP 516S User Manual 47

Details please refer to the instructions in the manual: How to Do

customized Resolution.

OUTPUT ADJUST: Output adjust menus, the sub-menu as following:

DVI1, setting as following:

DVI MODE: Can set the protocol as HDMI or DVI, default is DVI output,

HDMI signal output will enable when HDMI option checked.

BIT DEPTH: Can set the image bit depth.

DATE RANGE: DVI1 output range, can set as RGB (graphic mode or

YCbCr (video mode), RGB output scale range is between 0-255, YCbCr

range from 16 to 235.

DE ADJUST: DE adjust, the sub-menu as following:

DE ON/OFF: Can choose to open or close, when choose open, it can be

adjusted to DE, as follows:

H SIZE: Width setting.

V SIZE: Height setting.

H POS: Horizontal phase setting.

V POS: Vertical phase setting.

When the signal source of the screen appear black side, can use this

function to shift the black out of the screen.

RESET: If image quality distorts by improper operation, it can be recover by

reset.

DVI2: Including DVI MODE, DATA RANGE, DE ADJUST, and RESET,

same with DVI1.

Note

Only comments to professional operator.

SCALE：It can adjust the image scale size and image position settings

including as follows:
