6. System Setup and Operations
Interface and Input Signal Option
VSP 516S User Manual 89
Note
33. DVI2 + VGA output, output DVI video signal or VGA video signal,
connect the display or other device with DVI or VGA interface, and output
the signal by DVI-I interface. Support resolution format as following:
800×600×60, 1024×768×60, 1024×768×75, 1280×720×50, 1280×720×60,
1280×768×60, 1280×800×60, 1280×1024×60, 1360×768×60,
1366×768×60, 1400×1050×60, 1440×800×60, 1440×900×60,
1600×1200×60, 1680×1050×60, 1920×1080×50, 1920×1080×60,
1920×1120×60, 1920×1200×60, 2048×1152×60, 2560×812×60,
2560×816×60.
In addition to CONT part and send card and power interface outside, other
interface for video signal input interface.
CVBS（ BNC Port）Can receive standard video signal from players,
cameras etc. Input supported resolution 480i and 576i via BNC. Supported
standards include: PAL, NTSC and SECAM.
S-Video（DIN 4 Port）Can used to input S-Video signal.
DVI（DVI-I Port）Computer graphics interface may receive the DVI output
interface can also through the DVI turn HDMI cable to connect the
computer graphics HDMI output or DVD HDMI output.
YPbPr（BNC Port）Can support DVD player, video signal. Through the
BNC × 3 this equipment component interface, as the Pb, Y, Pr.
VGA（DB15 Port）Can support HD player, computer, video signal. Through
the DB15 interface input signal.
Displayport interface: Input the video signal from HD player, computer,
input signal via displayport interface.
3G-SDI（BNC Port）Can receive video signal from HD player and radio
To Next Page
