Ricoh Aficio MP C3300 Function Guide

1. Press [Manual Entry].
2. Press [SMB].
3. Press [Browse Network] under the path name field.
Domains or workgroups on the network appear.
4. Select the domain or workgroup in which the destination folder is located.
5. Select the client computer that has the destination folder.
If you cannot find the computer you are looking for, press [Up One Level] and browse that level.
If authentication is required to access the selected computer, the authentication screen appears. To
authenticate, enter the user name and password.
6. Select the destination folder.
When the selected folder has sub-folders, the sub-folders list appears.
If you cannot find the destination folder, press [Up One Level], and then search for the folder at that
level.
7. Press [OK] twice.
• If authentication is required to access the folder, the login screen appears. Enter the user name
and password.
• If you change the protocol after entering the path name, user name, or password, a confirmation
message appears.
Specifying Scan to Folder Destinations
69
2

Ricoh Aficio MP C3300 Specifications

General

Print Technology	Laser
Print Speed (Black)	33 ppm
Print Speed (Color)	33 ppm
Max Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Technology	CCD
Copy Speed	33 cpm
Max Paper Size	A3
Monthly Duty Cycle	150, 000 pages
Copy Resolution	600 dpi
Multiple Copy	Up to 999 copies
Scan Speed (B&W)	50 ipm
Scan Speed (Color)	50 ipm
Paper Output Capacity (Maximum)	500 sheets
Processor	600 MHz
Memory (Standard)	1 GB
Memory (Maximum)	1.5 GB
Power Consumption (Maximum)	1.5 kW
Functions	Print, Copy, Scan
Zoom	25% - 400%
Scan Destinations	Email, Folder, USB
Paper Weight	60 - 220 gsm
Hard Disk Drive	80 GB
Interface	USB 2.0, Ethernet
PDL (Page Description Language)	PCL6, PostScript 3
Operating Systems Compatibility	Windows, Mac, Linux
Power Source	220 - 240 V
