REF. D. PIN NO. SIGNAL WIRE COLOR
P1
1 +3.3V ORANGE
2 +3.3V ORANGE
3 COM BLACK
4 +5V RED
5 COM BLACK
6 +5V RED
7 COM BLACK
8 PW-OK GRAY
9 +5Vab PURPLE
10 +12V YELLOW
11 +12V YELLOW
12 +3.3V ORANGE
13
+3.3V ORANGE
+3.3VS BROWN
14 -12V BLUE
15 COM BLACK
16 PS-ON GREEN
17 COM BLACK
18 COM BLACK
19 COM BLACK
20 - -
21 +5V RED
22 +5V RED
23 +5V RED
24 COM BLACK
Test the Voltage Supplies
183
