Ricoh MP 402SPF Service Manual

4.Replacement and Adjustment
150
3. Remove the speaker [A].
PSU
 Turn OFF the main power and unplug the power cord before replacing the PSU.
 Do not touch the areas outlined in red in the following diagrams when replacing the PSU. Residual charge on
the board may cause electric shock.
100V
200V

Ricoh MP 402SPF Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Maximum Print Resolution	1200 x 1200 dpi
Maximum Paper Capacity	1, 600 sheets
Duplex Printing	Yes
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Maximum Paper Size	A4
Warm-up Time	21 seconds
Memory (RAM)	2 GB
Fax Transmission Speed	33.6 Kbps
Copy Resolution	600 x 600 dpi
Operating System Compatibility	Windows, Mac OS, Linux
Connectivity	USB, Ethernet, Wi-Fi
Control Panel	Touchscreen
Mobile Printing	Yes
Hard Disk Drive	320 GB (Optional)
Network Connectivity	Ethernet
Print Speed	Up to 42 ppm (Letter)
Copy Speed	Up to 42 cpm (Letter)
