The transfer current is adjusted in accordance with the paper tray (paper feed unit, bypass tray, and duplex tray),
paper size, paper type, and print number of sheets.
ï‚· You can adjust these levels (SP2-301 T bias control).
 Increasing the transfer current may produce ghost images–part of the image near the leading edge
reappears on another part of the page.
ï‚· Increasing the transfer current might damage the OPC drum.
Paper Separation
The paper separates from the OPC drum because of the curvature of the OPC drum and because of the grounded
discharge plate downstream of the transfer roller. Irregularities in the toner image at the time of separation are
prevented by an electric field.
Transfer Roller Cleaning
Toner may transfer to the roller surface following a paper jam or if the paper is smaller than the image. Periodic
cleaning of the roller is required to prevent this toner from migrating back to the rear of new printouts.
The machine cleans the roller at the following times:
ï‚· After initial power on.
ï‚· After clearing of a copy jam
ï‚· At the end of a job
The PSU first supplies a negative cleaning current (about -4 A) to the transfer roller, causing negatively charged toner
on the roller to move back to the drum. It then applies a positive cleaning current (+5 A) to the roller, causing any
positively charged toner to migrate back to the drum.
Related SPs
ï‚· 2-301-xxx [T bias Control]:
Use these SPs to adjust the power output and power coefficient used to transfer the toner image from drum to
paper. Four separate voltages are applied: before the leading edge, at the leading edge of the paper, across the
image area, and at the trailing edge of the paper.
