Notation Conventions
Some field values (or ranges of values) are specified assuming a unit of measure of 14400 L-units per
10 inches (5670 L-units per 10 centimeters). To determine supported values for a unit of measure of
2400 L-units per 10 inches (945 L-units per 10 centimeters) use the following steps.
1.
Convert the specified value from hex (2's complement) to decimal.
2. Divide the + or - decimal number by 6.
3. Round to the nearest integer.
4. Convert the + or - decimal value back to hex (2's complement).
For example, if the specified value is X'8000' the following steps would be performed.
1. 8000(H) = -32768(D)
2. -32768/6 = -5461.333
3. -5461(D) = EAAB(H)
