Offset Range Meaning Error Code
n+13 GCGID PROCESSING FLAGS
Bit 0: 0 Defined
Bit 0: 1 Undefined
Bit 1: 0 Printing
Bit 1: 1 Nonprinting
Bit 2: 0 Incrementing
Bit 2: 1 Nonincrementing
Bit 3: 0 Reserved
Bit 4: 0 Retired
Bit 4: 1 Retired
Bit 5 - 7:
0000
Reserved
• If the code point specified in VARIABLE SPACE CODE POINT is not contained in the associated
font character set, the printer will use a character increment of 333 relative units for typographic
and proportionally spaced fonts and 600 relative units for fixed pitch, uniform character increment
fonts.
•
GCSGID/CPGID will be used for CMAP matching (DBCS), in all other instances they will be
ignored.
Load Font
LF1 Format
When downloading a fully described font (LF1 format), the Load Font (LF) carries a series of character
raster pattern bit strings. Consecutive Load Font commands are supported for downloading the LF1 font
character patterns.
10. Loaded Font Command Set
214
