Load Font Index
This command is 32 + (256 × 16) (the (256 × 16) byte field is not always required) bytes long. It
contains general information needed to print the patterns and a description of the characteristics of each
of the 256 possible code points. Each font can have from one to four associated font indices.
Each index is loaded by a separate Load Font Index command. This command can only be issued in
Home State.
Offset Range Meaning Error Code
0-1 X'0001'-
X'7EFF'
FONT HOST ASSIGNED ID (HAID) X'0218..0
2'
2 SECTION ID X'0243..0
2'
X'00' Single byte
X'41'-X'FE' Double-byte section
3 FLAGS
Bit 0: 0/1 VARIABLE SPACE: Disabled/Enabled
Bits 1-7:
0000000
Reserved
4-5 FONT INLINE SEQUENCE X'0240..0
2'
X'0246..0
2'
X'0000' 0 degrees
X'2D00' 90 degrees
X'5A00' 180 degrees
X'8700' 270 degrees
6-7 X'0000' Reserved
8-9 X'8000' -
X'7FFF'
UNIFORM or MAXIMUM BASELINE OFFSET X'023C..
02'
10-11 X'8000' -
X'7FFF'
UNIFORM or MAXIMUM CHARACTER INCREMENT X'023C..
02'
12-13 X'0000' Reserved
