Finishing Operation Triplet
The Finishing Operation triplet specifies a specific finishing operation to be applied to a collection of
sheets.
Offset Range Meaning Error Code
0 X'09' LENGTH X'027A..
01'
X'027B..
01'
1 X'85' Finishing Triplet ID
2 OPERATION TYPE X'027C..
03'
X'027C..
09'
X'01' Corner Staple
X'03' Edge Stitch
X'0A' Punch
X'12' Saddle Stitch In
3-4 X'0000' Reserved
5 REFERENCE CORNER X'027C..
04'
X'01' Top-right corner (SEF only)
X'02' Top-left corner
X'03' Bottom-left corner
X'FF' Device default corner (top left corner)
REFERENCE EDGE
X'02' Top edge (SEF only)
X'03' Left edge (LEF only)
X'FF' Device default edge (top edge-SEF, left edge-LEF)
Execute Order Home State (XOH)
113
