Offset Range Meaning
Error
Code
25-26 WIDE-TO-NARROW RATIO (WE|NE) X'0409..0
0'
X'0000' Not Applicable Note 2
X'0002' 2: 1
X'0003' 3: 1
X'0014' to
X'001E'
2.0: 1 - 3.0: 1
X'00C8' to
X'012C'
2.00: 1 - 3.00: 1
X'FFFF' Printer Default as specified by Bar Code Type (Byte 16)
27-end Ignored
• The Font Local ID specified in BCDD Byte 18 should be OCR-A, OCR-B or Code 128 dependent
on the Bar Code Type specified in BCDD Byte 16. The default Font Local ID and Bar Code Type
relationships are as follows:
OCR-A OCR-B
Code 128
Code 3 of 9
MSI
2 of 5 Industrial
2 of 5 Matrix
2 of 5
Interleaved
Codabar
UPC-A
UPC-E
UPC 2-Digit Add-on
UPC 5-Digit Add-on
EAN-8
EAN-13
EAN 2-Digit Add-on
EAN 5-Digit Add-on
• Wide-to-Narrow Ratio (BCDD Bytes 25-26) is only valid for the following Bar Code Types:
• X'01' 3 of 9
• X'02' MSI
• X'0A' 2 of 5 Industrial
• X'0B' 2 of 5 Matrix
• X'0C' Interleaved 2 of 5
6. Bar Code Command Set
192
