Ricoh MP 9003 Series User Manual

5. Print
This chapter describes frequently used printer functions and operations. For information not included in
this chapter, see Print available on our website.
Quick Install
You can install the printer drivers easily from the CD-ROM provided with this machine.
Using Quick Install, the PCL 6 printer driver is installed under network environment, and the Standard
TCP/IP port will be set.
• Manage Printers permission is required to install the drivers. Log on as an Administrators group
member.
1. Click [Quick Install] on the installer screen.
2. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next >].
3. Click [Next >].
4. Select the machine model you want to use in the [Select Printer] dialog box.
5. Click [Install].
6. Configure the user code, default printer, and shared printer as necessary.
7. Click [Continue].
The installation starts.
8. Click [Finish].
When you are prompted to restart your computer, restart it by following the instructions that
appear.
9. Click [Exit] in the first window of the installer, and then take out the CD-ROM.
109

Ricoh MP 9003 Series Specifications

General

Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Standard Features	Print, Copy, Scan
Memory (RAM)	2 GB
Hard Disk Drive	320 GB
Copy Resolution	600 x 600 dpi
Print Speed	90 ppm
Paper Capacity	8, 300 sheets maximum
Paper Size	A3, A4, A5, B4, B5
Paper Weight	52 to 300 g/m²
Optional Features	Fax, Additional Paper Trays, Finisher Options
Power Source	AC 220-240V, 50/60Hz
Scan Resolution	600 x 600 dpi
Copy Speed	90 ppm
Fax Resolution	200 x 200 dpi
Network Connectivity	Ethernet
