Ricoh MP C2800 User Manual

• wlan can be specified only when the IEEE 802.11 interface is installed.
Interface name Interface configured
Ether Ethernet interface
Wlan IEEE 802.11 interface
Address configuration
Use the following command to configure a WINS server IP address:
wins “interface_name” {primary|secondary} “IP address”
• Use the “primary” command to configure a primary WINS server IP address.
• Use the “secondary” command to configure a secondary WINS server IP address.
• Do not use “255.255.255.255” as the IP address.
NBT (NetBIOS over TCP/IP) Scope ID Selection
You can specify the NBT scope ID.
msh> wins “interface_name” scope “scope ID”
• The scope ID can be entered using up to 31 alphanumeric characters.
• Be sure to specify the interface.
• wlan can be specified only when the IEEE 802.11 interface is installed.
Interface name Interface configured
Ether Ethernet interface
Wlan IEEE 802.11 interface
wsmfp
Use the “wsmfp” command to view and configure WSD (Device), WSD (Printer) and WSD (Scanner)
settings.
Viw settings
msh> wsmfp
Comment settings
msh> wsmfp comments “comment”
• If you do not specify a comment, current setting is displayed.
Location configuration
mah> wsmfp location “location”
4. Monitoring and Configuring the Printer
200
4

Ricoh MP C2800 Specifications

General

Print Technology	Laser
Print Speed	28 ppm
Max Print Resolution	600 x 600 dpi
Copier Speed	28 cpm
Copy Resolution	600 x 600 dpi
Reduction/Enlargement	25% - 400%
Fax Speed	33.6 kbps
Functions	Print, Copy, Scan, Fax
Automatic Duplexing	Yes
Hard Drive	80 GB
Scan Resolution	600 dpi
Connectivity	USB 2.0, Ethernet
Operating System Compatibility	Windows, Mac
