3. Upper right cover
Open this cover when a paper jam occurs.
4. Duplex unit
Open this cover when a paper jam occurs.
5. Tray 2 right cover
Open this cover when a paper jam occurs.
6. Lower right cover
Open this cover when a paper jam occurs.
7. Paper guides
When loading paper in the bypass tray, align the paper guides flush against the paper.
8. Bypass tray
Use to copy or print on OHP transparencies, adhesive labels, and paper that cannot be loaded in the paper
trays.
9. Extender
Pull this extender out when loading A4, 8
1
/
2
× 11 or larger size paper in the bypass tray.
Rear and left view
1. Vents
Prevent overheating.
Guide to Names and Functions of Components
29
