CPT019
12
1. When the core of the paper roll is 50.8 mm (2 inches)
2. When the core of the paper roll is 76.2 mm (3 inches)
Paper roll direction
When loading the paper roll to the paper holder and machine, make sure that the edge of the
paper feeds from top of the roll toward the front.
CPT032
1
1. Right flange
1. Press the [Home] key on the top left of the control panel, and press the [Copier] or
[Printer] icon on the [Home] screen.
CPL011
Make sure that "Ready" appears on the screen.
Loading Paper into the Paper Input Location
109
