Load the paper roll when the power of the machine is on.
Check that the output basket is in basic mode before loading a paper roll. For details, see "Setting the
Output Basket", Getting Started .
You can load the paper roll into Paper Input Locations 1 and 2. Each paper input location is loaded in
the same way. In the following example procedure, the paper roll is loaded into Paper Input Location 1.
The paper roll is heavy and may need to be lifted by two people.
When replacing paper holder to other paper roll, place the paper roll on a flat surface.
Names of the parts of the paper holder
5
1
4
2
CPT039
3
3
1. Left flange
2. Spool
3. Paper roll adjustment levers
4. Right flange
5. Lock lever
Position of the paper roll adjustment levers
Switch the paper roll adjustment levers depending on the internal diameter of the paper roll. There
are three paper roll adjustment levers on each flange. Make sure that all six levers are in the same
position.
When the core of the paper roll is 50.8 mm (2 inches), open the paper roll adjustment levers.
When the core of the paper roll is 76.2 mm (3 inches), close the paper roll adjustment levers.
8. Adding Paper and Ink
108
