11. Remove the left flange from the spool.
CPT020
12. Remove both the right flange and spool from the paper roll.
CPT018
13. Adjust the paper roll adjustment levers of both flanges, according to the core of the paper
roll you want to load.
14. Insert the flange with the spool from the right side of the paper roll until it touches the
paper roll.
CPT021
8. Adding Paper and Ink
112
