Ricoh MP CW2200SP User Manual

15. Insert the spool into the left flange.
CPT022
16. Holding the right flange with your hand, insert the left flange until it touches the paper
roll.
17. Lower the lock lever on the left flange.
CPT040
18. Place the paper roll on the flat place in front of the bearing.
CPT023
19. Place the right and left edge of the shaft into the bearing.
Turn the paper roll so that the edge of the paper feeds from the top of the roll towards the front.
Loading Paper into the Paper Input Location
113
